Reachability contours
Generate reachability contours from a starting point. Shows how far you can travel within a given time limit (in minutes) or distance limit (in kilometres). Returns polygon boundaries you can display on a map. Supports multiple contours in one request, so you can show 5, 10, and 15-minute ranges together. For “what’s reachable from X” queries, pass from as a place name and the origin is geocoded for you — there is no need to call geocode first. If you already have coordinates, pass location instead.

​
Example prompts

  • “How far can I walk in 15 minutes from Liverpool Street station?” → get_isochrone(from="Liverpool Street station, London", contours=[{time: 15}], travel="pedestrian")
  • “Show me the area I can cycle to in 20 minutes from my office” → get_isochrone(location={lat: ..., lon: ...}, contours=[{time: 20}], travel="bicycle")
  • “What’s within a 5km drive of this warehouse?” → get_isochrone(location={lat: ..., lon: ...}, contours=[{distance: 5}], travel="auto")
  • “Compare 10-minute and 30-minute walking ranges from Kings Cross” → get_isochrone(from="Kings Cross, London", contours=[{time: 10}, {time: 30}], travel="pedestrian")

​
What you get back

Each contour is returned with full polygon coordinates, a vertex-count + bbox summary, and a list of named anchors inside the polygon (see below). The response also includes the origin point and travel type used. Pass compact: true to suppress the polygon coordinates and the render envelope when the caller only needs summary fields.

​
reachable_places — named anchors inside the polygon

For each contour, the response includes a reachable_places array: named venues, neighbourhoods, parks, stations, and landmarks that fall inside the polygon, ordered by relevance. This turns a polygon (which an LLM can’t render) into something an LLM can actually speak:
“In 15 minutes on foot from Kings Cross you can reach Russell Square, Holborn, Camden Town and Bloomsbury.”
Each place carries name, label, place_type, and coordinates. This is best-effort enrichment: if no named anchors can be resolved for a contour, reachable_places is omitted and the rest of the response goes through unchanged.

​
Contour ordering

Contours are returned sorted ascending by value — the smallest reach first, regardless of input order. So contours: [{time: 10}, {time: 5}] and contours: [{time: 5}, {time: 10}] both produce a response with the 5-minute contour at index 0.

​
Map rendering

Each contour ships with a vertex-count + bbox summary plus a polygon layer per contour in the render envelope (with style_hints.contour_value carrying the contour’s value for gradient ordering). Drop the layers straight into your map library. Pass compact: true for summary-only responses. See response defaults & controls and render envelopes.

​
Example response

{
  "structuredContent": {
    "origin": { "lat": 51.532, "lon": -0.124 },
    "travel": "pedestrian",
    "contours": [
      {
        "metric": "time",
        "value": 15,
        "geometry_summary": { "type": "Polygon", "vertex_count": 137, "bbox": {/* … */} },
        "reachable_places": [/* named anchors inside the polygon */]
      }
    ],
    "render": [
      {
        "kind": "polygon",
        "label": "15-minute reach",
        "data": {/* GeoJSON Feature with full Polygon geometry */},
        "bbox": [/* … */],
        "style_hints": { "contour_value": 15, "contour_label": "15-minute reach" }
      }
    ]
  }
}
